Internal dimensions 2630 x 2430 xh 2030 mm.
Internal volume 12,97 m³.
Door with useful passage 800 x 1900 mm (positioning of the door at choice, on the 4 sides).
Door seal equipped with a peripheral heating cord (for negative T°).
Vacuum valve (for negative temperature).
Multipurpose chamber for positive or negative temperature, thickness of walls, floor and ceiling 80 mm, modulation with panels from 200 to 1200 mm width (200+200+200 ...).
Panels made of white lacquered galvanized steel sheet "non-toxic and anti-scratch".
Insulation in high density injected polyurethane (43 Kg/m3), ecological (without CFC).
Locking of the panels by incorporated "eccentric" hooks.
Reinforced floor in 12 mm multiplex wood, covered with a phenolic anti-slip "honeycomb" resin, supporting a load of 4000 kg/m² (140 Kg point load).
Peripheral corners at 90° with specific caps at the ends, also insulated with polyurethane (50 Kg/m3) avoiding any possible thermal bridge.
The corners and edges of the floor, ceiling and walls are all rounded (R15 mm) and also insulated with polyurethane (50 Kg/m3).
Swinging door thickness 80 mm also insulated with polyurethane (43 Kg/m3), with right hinges (on request, possibility of left hinges: CGC/BF), very strong, reinforced with a peripheral frame in anodised aluminum, provided with a magnetic seal in EPDM "pressure" (easy replacement, without tools), adjustable rising hinges and with stop at 100°, external handle with key lock, internal closing with safety device.
Panel certified in classification "B-S3,d0" according to the UNI EN 13501-1:2009 standard.
The equipment is built in compliance with the current CE regulations.
| Product Dimensions | W2790 x D2590 x H2190 |
